■ 平面管
形状 | REF | PCB | 芯数 | 规格书 | ||||
外形尺寸 (宽x高x厚mm) | 发光区域 (宽x高mm) | 名称 | PCB型号 | PIN针数 | 电路 | |||
方形 | 7.6x4.6x8.0 | 7.0x4.0 | CPB0408 | A | 2 | 1芯 | 1 |  |
20.0x7.0x6.2 | 18.8x5.8 | CPB0720 | A | 6 | 3芯 | 3 | | |
B | 6 | 双色3芯串联 | 6 | |||||
C | 6 | 3芯串联 | 3 | |||||
D | 6 | 3芯并联 | 3 | |||||
15.0x15.0x10.8 | 13.0x13.0 | CPB1515 | 2 | 二串二并 | 4 | | ||
40.0x20.0 | 39.0x19.0 | CPB2040 | 2 | 5串2并 | 10 | | ||
22.0x32.0x10.0 | 20.0x30.0 | CPB2232 | 3 | 4串2并 | 8 | | ||
27.0x27.0x11.0 | 25.0x25.0 | CPB2727 | A | 2 | 2串2并 | 4 | | |
B | 2 | 4芯并联 | 4 | |||||
C | 4 | 4芯并联x2色 | 8 | |||||
40.0x40.0x11.0 | 37.2x37.2 | CPB4040 | A | 2 | 9芯并联 | 9 | | |
B | 2 | 9芯串联 | 9 | |||||
C | 2 | 6串2并 | 12 | |||||
圆形 | Φ10.0x8.0(直径x高) | Φ8.8 | CPBR8 | 2 | 2芯串联 | 2 | | |
Φ11.5x10.0 | Φ10.0 | CPBR12 | 2 | 2芯串联 | 2 | | ||
Φ18.0x11.0 | Φ16.3 | CPBR18 | 2 | 5芯串联 | 5 | | ||
Φ25.0x12.0 | Φ23.0 | CPBR25 | A | 2 | 5串2并 | 10 | | |
B | 2 | 10芯串联 | 10 | |||||
